PAP Paramotors:
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PA125 TECHNICAL SPECIFICATION |
||||
| Chasis 1250 mm | Chasis 1400 mm | Chasis 1450 mm | ||
| Motor Type | PA125 single cylinder, 2-stroke, forced air cooled | |||
| Cylinder | 125 cc (54x54mm) | |||
| Carburettor | Walbro 24 mm. | |||
| Power & Ignition | 22 CV / 9580 R.P.M. Electronic | |||
| Reduction gear | Mechanical in oil bath, inclined teeth | |||
| Reduction ratio | 1/3,65 | |||
| Transmission | Centrifugal clutch | |||
| Start | Manual | |||
| *Thrust (kg) | aprox. 58kg | aprox. 64kg | aprox. 66kg | |
| Fuel | Leaded or unleaded Super grade + synthetic oil 2,5% | |||
| Fuel tank | 13,5 L | |||
| *Autonomy hours | aprox. 3h. | |||
| Cage | Stainless Steel / T.I.G. | |||
| Cage in 2 parts | YES | YES | YES | |
| Cage in 3 parts T3 | YES | YES | YES | |
| Cage Luggage Bag | YES 3 parts | YES 3 parts | YES 3 parts | |
| Chassis Luggage Bag | Optional | Optional | Optional | |
| Wood propeller (cm) | YES | YES | YES | |
| Carbon fibre propeller | Optional | Optional | Optional | |
| Paramotor weight | 26 kg. | 27 kg. | 27 kg. | |
| Max. Pilot weight | 100 kg. | 120 kg. | 120 kg. | |
| Recommended Pilot weight | 75 kg. | 100 kg. | 100 kg. | |
| Harness size: S, M, L, XL | Sup´Air Special PAP, Wood Board | |||
| Size (cm) | 125 x 125 x 43 | 140 x 140 x 43 | 145 x 145 x 43 | |
| Propeller case | YES | YES | YES | |
| Head Rescue System | YES | YES | YES | |
| Cuenta RPM | Optional | Optional | Optional | |
| * Thrust, autonomy and general performance depend greatly on the glider, the altitude and the pilot, so the data offered here must be taken only as reference data. | ||||
